Batching Cog Hopper
Cov khoom saib ua ntej
AGICO's Batching Plant Hopperyog ib tug ntsug los yog inclined lifting ntaus ntawv tsim rau pob zeb batching nroj tsuag. Nws yog tsuas yog siv los thauj cov aggregates xws li xuab zeb thiab pob zeb los ntawm theem av mus rau lub tov khoom los yog cia rau hauv kom zoo thiab raug. Raws li ib qho ntawm AGICO cov khoom tseem ceeb hauv kev lag luam khoom vaj khoom tsev, qhov hopper system no yog ua los ntawm siab -lub zog hnav- cov hlau tsis muaj zog. Nws muaj cov qauv compact thiab ua kom ntev - lub sijhawm ua haujlwm ruaj khov hauv kev ua haujlwm hnyav.
AGICO's Batching Plant Hopper yog tshwj xeeb tshaj yog paub txog nws cov qauv tsim qauv thiab cov khoom siv thoob ntiaj teb kev nyab xeeb (xws li ob qhov kev txwv kev hloov pauv thiab tiv thaiv- lub caij nplooj zeeg mechanisms). Nws tau raug xa tawm hauv ntim rau cov teb chaws Asia, Africa, thiab South America. Lub hopper no haum rau me me mus rau nruab nrab pob zeb ua vaj tse xws li HZS25 txog HZS75.
Khoom Specification
AGICO's Batching Plant Hopper muaj tsib yam tseem ceeb: lub hopper lub cev, hnyav - lub luag hauj lwm rails, tsav mechanism (lub cev muaj zog + reducer + winch / hlau hlua), tswj system, thiab cov khoom siv kev nyab xeeb. Nws cov qauv tsim tseem ceeb yog "spill-cov qauv pov thawj" thiab "tus kheej- lubricating rail log," uas daws tau cov teeb meem ntawm cov khoom spillage thiab rail jamming thaum nqa. Cov ntsia hlau yog ua los ntawm kub- dov U-channel steel los yog I-beam steel los tiv thaiv deformation ntev - siv sijhawm. Lub cev muaj zog tsav yog YE3 siab -nqi zog- txuag lub cev muaj zog, ua ke nrog electromagnetic nres, muab cov lus teb ceev thiab qhov tseeb.
Cov txheej txheem ua haujlwm ntawm batching cog hopper
1. Batching
Hauv theem batching, AGICO Batching Plant Hopper tau txais kev sib sau ua ke los ntawm cov khoom siv hluav taws xob hauv hluav taws xob tom qab qhov hnyav. Qhov no xyuas kom meej cov khoom sib piv rau txhua batch.
2. Kev nqa
Lub kaw lus tswj tau pib YE3 siab- lub cev muaj zog ntawm AGICO Batching Plant Hopper, uas tsav lub winch thiab txav lub hopper smoothly upward nrog hnyav - lub luag haujlwm rails.
3. Tso tawm
Thaum AGICO Batching Plant Hopper mus txog qhov chaw tso tawm sab saum toj, nws lub log pem hauv ntej nkag mus rau hauv kev tawm. Lub hopper lub cev qaij cia li los yog lub qhov rooj tawm qhib, tso cai rau cov khoom sib xyaw kom xaub mus rau hauv lub tov khoom nrog me me heev.
4. Rov qab los
Tom qab tso tawm, qhov khoob AGICO Batching Plant Hopper rov qab los rau hauv av chaw thau khoom yog txiav los yog manually, npaj rau lub voj voog tom ntej. Ib lub voj voog ua tiav feem ntau yuav siv sijhawm 60 txog 90 vib nas this.
Technical Parameter ntawm AGICO Batching Cog Hopper
| Parameter | Me Hopper | Nruab nrab Hopper | Loj Hopper |
|---|---|---|---|
| Muaj nuj nqi (L) | 800 – 1,200 | 1,500 – 2,000 | 2,500 – 3,000 |
| Siv tau Batching Plant Model | HZS 25 / HZS 35 | HZS50/HZS60 | HZS 75 |
| Lifting ceev (m / min) | 18 – 22 | 20 – 25 | 22 – 25 |
| Lub cev muaj zog (kW) | 5.5 – 7.5 | 7.5 – 11 | 11 – 15 |
| Rail Inclination Angle (degree) | 45 – 60 | 45 – 60 | 45 – 60 |
| Hlau hlua txoj kab uas hla (mm) | 11 – 13 | 13 – 16 | 16 – 18 |
| Tswj hom | Phau ntawv / Automatic | Tsis siv neeg | Tsis siv neeg |
| Daim Ntawv Qhia Tus Nqi (USD) | 1,000–1,000–5,000 | 5,000–5,000–15,000 | > $15,000 |
* Cov kev ntsuas saum toj no tuaj yeem kho raws li qhov xav tau ntawm qhov project. Cov nqi yog rau siv xwb.
Cov Khoom Zoo
Qhov tseem ceeb ntawm AGICO batching cog hopper
AGICO muab kev ua haujlwm siab thiab kev pab lub neej ntev batching hopper, thov hu rau peb kom tau txais kev qhia dawb.
Kev txuag nqi chaw
AGICO Batching Plant Hopper siv txoj kab ntsug lossis siab -lub kaum sab xis rail nqa tsim. Nws qhov chaw hauv pem teb tsuas yog 1/3 ntawm ib txoj siv conveyor. Nws yog tshwj xeeb tshaj yog haum rau batching nroj tsuag nrog tsawg qhov chaw, xws li cov nyob rau hauv nroog los yog roob. Cov nqi tsim kho hauv paus raug txo los ntawm kwv yees li 20% -30%.
Kev txuag hluav taws xob tseem ceeb
AGICO Batching Plant Hopper siv lub zog tsuas yog thaum lub sijhawm nqa. Kev siv hluav taws xob ib lub voj voog tsuas yog 5.5-15 kW, thaum siv txoj siv sia yuav tsum khiav tsis tu ncua. Rau kev tsim khoom me me rau nruab nrab, cov nqi hluav taws xob niaj hnub tuaj yeem txuag tau los ntawm 15% -25%.
Hnav-Resistant Design
Lub cev hopper ntawm AGICO Batching Plant Hopper yog ua los ntawm 6-10 hli hnav-cov hlau tsis muaj zog. Nws tseem tuaj yeem nruab nrog kev xaiv siab -chromium cam khwb cia hlau liners lossis polyurethane hauv ob sab phlu. Qhov no ua rau nws haum rau abrasive aggregates xws li dej pebbles thiab crushed pob zeb.
High Adaptability
AGICO Batching Plant Hopper tuaj yeem ua haujlwm nrog ntau hom khoom sib xyaw. Lifting qhov siab thiab tawm lub kaum sab xis tuaj yeem hloov kho ntawm qhov chaw (45℃-60 degree). Tswj hom muaj xws li phau ntawv, tsis siv neeg, thiab tej thaj chaw deb. Nws tau dhau ISO thiab CE cov qauv kev nyab xeeb, ua tau raws li qhov yuav tsum tau txais rau cov haujlwm txawv teb chaws.
FAQ
Q: Yuav ua li cas xaiv ntawm AGICO Batching Plant Hopper thiab siv conveyor rau cov pob zeb ua pob zeb?
A: Yog tias koj cov nroj tsuag tsim muaj peev xwm tsawg dua lossis sib npaug li 75 m³ / h, thiab qhov chaw ntawm qhov chaw muaj tsawg lossis cov peev nyiaj nruj, AGICO Batching Plant Hopper yog tus nqi ntau dua - kev xaiv zoo. Ib txoj siv conveyor yog tsim rau siab - muaj peev xwm ntau lawm ntau dua los yog sib npaug rau 120 m³ / h. Lub AGICO hopper system yuav tsum tau 20% -40% tsawg pib nqis peev tshaj ib txoj siv conveyor. Nws lub zog noj yog concentrated nyob rau hauv tsis tu ncua ua hauj lwm cycles, ua rau nws ntau haum rau me me mus rau nruab nrab batch ntau lawm nrog nquag hloov khoom.
Q: Yuav ua li cas AGICO daws qhov kev nyab xeeb ntawm txoj hlua hlau tawg thaum lub sij hawm ntev - siv lub lifting hopper?
A: AGICO Batching Plant Hopper los ntawm tus qauv nrog kev tiv thaiv triple: "dual ywj siab xaim hlua nqa + cov neeg kho tshuab poob ntes + hluav taws xob txwv hloov." Cov hlua hlau muaj 6 × 37 los tiv thaiv- kev sib hloov kev tsim kho, nrog rau kev nyab xeeb ntawm ntau dua lossis sib npaug li 8 npaug ntawm cov khoom ntsuas. Peb kuj muaj kev xaiv tsis siv neeg hlau hlua nro xyuas qhov system. Yog hais tias qhov txawv txav los yog hlau tawg tshwm sim ntawm ob sab, lub kaw lus tam sim ntawd suab lub tswb thiab nres lub lifting lag luam, tiv thaiv ib qho kev huam yuaj "runaway hopper".
Q: Lub AGICO Batching Cog Hopper puas tuaj yeem ua tau zoo heev los yog ntub dej aggregates?
A: Yog. Lub AGICO Batching Plant Hopper tuaj yeem haum nrog cov hnav khaub ncaws hloov pauv hauv lub hopper (siab-chromium cam khwb cia hlau lossis NM400 steel phaj), txuas ntxiv hnav lub neej los ntawm 2 mus rau 3 zaug. Rau kev sib sau ua ke nrog cov dej noo siab lossis cov ntaub ntawv nplaum, peb muab cov khoom siv los tiv thaiv -polyurethane liners thiab ib qho nkhaus hopper hauv qab tsim, uas txo cov khoom tsim thiab arching. Qhov kev tso tawm seem tuaj yeem tswj tau li ntawm 2%.
Q: Puas yog AGICO muab cov kev pabcuam uas tsis yog - tus qauv hloov kho, piv txwv li rau cov nroj tsuag qub retrofitting lossis tej yaam num uas txwv qhov siab?
A: Yog. Nrog rau ntau tshaj 20 xyoo ntawm kev tsis yog- tus qauv tsim, AGICO tuaj yeem muab cov kev daws teeb meem rau cov xwm txheej xws li qhov siab ntawm cov nroj tsuag tsis sib xws, cov hauv paus tsis sib xws, lossis qhov yuav tsum tau ua kom tsis sib xws tsis yog - tus qauv sib tov tso tawm qhib. Cov no suav nrog kev kho tsheb ciav hlau (txog 70 degree), luv dua hopper ntev, sab-tipping paug, lossis hauv qab- cov qauv tawm. Peb kuj muab tag nrho - cov kev pabcuam txheej txheem los ntawm qhov chaw tshawb fawb thiab kos duab tsim rau kev taw qhia kev teeb tsa.
